Stainless Steel Mesh SS316 Filter Wire 0.5mm, 10 Micron to 400 Micron

SS 316 Filter Wire Mesh for Export

Hehua exports filter wire mesh made of ss316 and 316L in rolls or meters to U.S.A., Japan, Turkey, Saudi Arab. Recently exported filter mesh cloth products as follows. Common weaving involved in this type of filter wire mesh is Plain or Twill Weave unless specified. The filter rating is not listed, but available upon request. Customers with similar demand can contact us with your specific requirements.

SS 316 is a special stainless alloy due to the addition of 2% molybdenum. SS 316 mesh has increased resistance to corrosion by salts, acids and seawater. Also called 18-10 due to 18% chromium and 10% nickel. T316 melts at 2500 degrees F (1375 C) but its maximum recommended temperature for continuous service is 1500 degrees F. (815 C) and is useful for intermediate service up to 1650 degrees F (900 C).

Uses of 316 stainless steel wire mesh: processing of oils and foods, chemicals, and pharmaceuticals.

316 Stainless Steel Wire Mesh Sizes:
Roll Width: 36", 40",1m, 48", 60" ,1.2m
Roll Length: 25Ft, 50Ft, 30m, 100Ft, 50m

Export List Examples:

Item	Qty	Unit	Description
number	number	Square meter	Mesh SS 316 Filter Wire 0.5 mm
1	10	m^2	10 Micron
2	10	m^2	20 Micron
3	10	m^2	32 Micron
4	10	m^2	35 Micron
5	10	m^2	42 Micron
6	10	m^2	48 Micron
7	10	m^2	200 Micron
8	10	m^2	250 Micron
9	10	m^2	400 Micron

Further technical information including your aperture size requirements, weaving types, mesh weight and specific applications can help us give you a quick response.

Packing: Also please advise your packing details, otherwise we will provide our standard export packing for stainless steel filter mesh screen.

We also list common Specification of 316 stainless steel filter mesh for customers choice. OEM and ODM available.

Stainless steel wire mesh(plain weave)
Mesh	Wire diameter(mm)
4	1.5
6	1.1
8	0.9
10	0.8
12	0.7
14	0.7
16	0.6
20	0.5
40	0.25
50	0.23
60	0.19
80	0.14
100	0.11
120	0.10
150	0.063
180	0.06
200	0.053
250	0.043
270	0.04
300	0.044
325	0.035
350	0.03
400	0.03
500	0.025
Other specifications can be customized

SS Filter Mesh, 20 Micron

316 Micron Filter Mesh with Increased Resistance

20 Mesh 316 Stainless Steel Wire Mesh

SS Wire Mesh Filter Cloth
Wire Diameter: 16 gauge
Opening: 6 openings per linear inch
Mesh thickness:1.6mm
Material: SS316
Supplied in standard roll length
